Tuotenumero: 3238102
TRENDnet TPE-3524S 52-Port Gigabit Web Smart PoE+ Switch with 10G SFP+ Slots
Kytkin, 52-port, web, L2+, smart, 48 x 10/100/1000 (PoE+) + 4 x 10 Gigabit SFP+, työpöytä, telineeseen asennettava, PoE+ (410 W), TAA-yhteensopiva
Varastossa
Normaalihinta 685,00 €
482,30 €
384,30 € Ilman arvonlisäveroa
Ilmainen toimitus noutopisteeseen
1 kpl
Varastossa - 2-5 arkipäivän toimitus
TRENDnet's 52-Port Gigabit Web Smart PoE+ Switch with 10G SFP+ ports, model TPE-3524S, offers advanced L2+ features with enhanced traffic management controls to meet the evolving demands of SMB networks. This rack mountable IPv6-ready managed switch comes with an intuitive web-based interface. Advanced managed switch features include LACP to group ports together to increase bandwidth between switches, VLANs for segmenting and isolating virtual LAN groups, QoS for traffic prioritization, port bandwidth controls, and SNMP monitoring, making this a powerful solution for SMB networks. Improve voice performance by isolating and prioritizing VoIP traffic from normal data traffic with the easy-to-use voice VLAN feature.
Free up router resources by offloading routing processes to the managed switch by using the L2+ IPv4/IPv6 static routing feature to efficiently route traffic at the switch level. The dynamic ARP inspection feature helps protect connected devices from man-in-the-middle attacks by discarding malicious and invalid ARP packets. Take advantage of the available multicast and IGMP/MLD snooping features to optimize IP surveillance system performance, and minimize network traffic. This TRENDnet Web Smart Managed PoE+ Switch also features 10G SFP+ ports to support long-distance fiber networking applications.
Installers and integrators can save on equipment costs and reduce installation time with TRENDnet's Web Smart Managed PoE+ Switches by delivering up to 30W per port of PoE power and data over existing Ethernet cables. With PoE technology, users only need one set of cables to deliver both data and power. With this PoE+ managed switch, network PoE devices such as high-power wireless access points, PTZ and other advanced IP cameras, VoIP phone systems, IPTV decoders, access controls, and more.
Free up router resources by offloading routing processes to the managed switch by using the L2+ IPv4/IPv6 static routing feature to efficiently route traffic at the switch level. The dynamic ARP inspection feature helps protect connected devices from man-in-the-middle attacks by discarding malicious and invalid ARP packets. Take advantage of the available multicast and IGMP/MLD snooping features to optimize IP surveillance system performance, and minimize network traffic. This TRENDnet Web Smart Managed PoE+ Switch also features 10G SFP+ ports to support long-distance fiber networking applications.
Installers and integrators can save on equipment costs and reduce installation time with TRENDnet's Web Smart Managed PoE+ Switches by delivering up to 30W per port of PoE power and data over existing Ethernet cables. With PoE technology, users only need one set of cables to deliver both data and power. With this PoE+ managed switch, network PoE devices such as high-power wireless access points, PTZ and other advanced IP cameras, VoIP phone systems, IPTV decoders, access controls, and more.
Valmistaja
Tuotenumero
3238102
Malli
TPE-3524S
Ean
0710931162509
Valmistajan kotisivuille
Kytkin tyyppi
Hallittu
Basic kytkentä RJ-45 Ethernet-porttien määrä
48
Peruskytkentä RJ-45 Ethernet-porttien tyyppi
Gigabit Ethernet (10/100/1000)
SFP+ -moduulipaikkojen määrä
4
Verkkostandardit
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3ba, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G-tuki
Kyllä
Täysin kaksipuolinen
Kyllä
Puolidupleksi
Kyllä
Linkkien yhdistäminen
Kyllä
STP-Protokolla
Kyllä
Head-of-line (HOL) blocking
Kyllä
Ethernet LAN -datanopeudet
10,100,1000,10000 Mbit/s
VLAN-tuki
Kyllä
Virtuaalisen LAN:n ominaisuudet
Private VLAN, Tagged VLAN, Voice VLAN
VLAN:ien määrä
4094
MAC-osoitetaulukko
32000 entries
Kytkentäkapasiteetti
176 Gbit/s
Forwarding rate
130,95 Mpps
Jumbo Frames -tuki
Kyllä
Jumbo frames
9000
Laitteen puskurimuistiin
2 MB
DHCP-ominaisuudet
DHCP snooping
IGMP snooping
Kyllä
Multicast-tuki
Kyllä
Hallintaprotokolla
SNMP v1, v2c, v3
Telineasennus
Kyllä
Tuotteen väri
Musta
Uudelleenkäynnistyspainike
Kyllä
LED-merkkivalot
Kyllä
Tuulettimien määrä
3 tuuletin(ta)
Melutaso
42,7 dB
Keskimääräinen vikaantumisaika
74330 h
Voimanlähde
AC/PoE
Virtalähde mukana
Kyllä
AC-syöttöjännite
100 - 240 V
AC-syöttötaajuus
50/60 Hz
Tehonkulutus (maks.)
57,4 W
Virtalähteen suojausominaisuudet
Ylivirta, Oikosulku
Power over Ethernet -tuki
Kyllä
Tuettu Power over Ethernet (PoE) -tyyppi
PoE+
Power over Ethernet plus (PoE +) -porttien määrä
48
Power over Ethernet (PoE) -virta per portti
30 W
Power over Ethernet (PoE) arvioitu kokonaismäärä
410 W
Käyttölämpötila (T-T)
0 - 50 °C
Tuotteen leveys
440 mm
Tuotteen syvyys
310 mm
Tuotteen korkeus
44 mm
Paino
4,75 kg
Sertifiointi
CE
FCC
UL
Hallintaominaisuudet
Kytkin tyyppi
Hallittu
Liitettävyys
Basic kytkentä RJ-45 Ethernet-porttien määrä
48
Peruskytkentä RJ-45 Ethernet-porttien tyyppi
Gigabit Ethernet (10/100/1000)
SFP+ -moduulipaikkojen määrä
4
Verkko
Verkkostandardit
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3ba, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G-tuki
Kyllä
Täysin kaksipuolinen
Kyllä
Puolidupleksi
Kyllä
Linkkien yhdistäminen
Kyllä
STP-Protokolla
Kyllä
Head-of-line (HOL) blocking
Kyllä
Ethernet LAN -datanopeudet
10,100,1000,10000 Mbit/s
VLAN-tuki
Kyllä
Virtuaalisen LAN:n ominaisuudet
Private VLAN, Tagged VLAN, Voice VLAN
VLAN:ien määrä
4094
Datasiirto
MAC-osoitetaulukko
32000 entries
Kytkentäkapasiteetti
176 Gbit/s
Forwarding rate
130,95 Mpps
Jumbo Frames -tuki
Kyllä
Jumbo frames
9000
Laitteen puskurimuistiin
2 MB
Suojaus
DHCP-ominaisuudet
DHCP snooping
IGMP snooping
Kyllä
Monilähetysominaisuudet
Multicast-tuki
Kyllä
Protokollat
Hallintaprotokolla
SNMP v1, v2c, v3
Suunnittelu
Telineasennus
Kyllä
Tuotteen väri
Musta
Uudelleenkäynnistyspainike
Kyllä
LED-merkkivalot
Kyllä
Tuulettimien määrä
3 tuuletin(ta)
Suorituskyky
Melutaso
42,7 dB
Keskimääräinen vikaantumisaika
74330 h
Virranhallinta
Voimanlähde
AC/PoE
Virtalähde mukana
Kyllä
AC-syöttöjännite
100 - 240 V
AC-syöttötaajuus
50/60 Hz
Tehonkulutus (maks.)
57,4 W
Virtalähteen suojausominaisuudet
Ylivirta, Oikosulku
Power over Ethernet (PoE)
Power over Ethernet -tuki
Kyllä
Tuettu Power over Ethernet (PoE) -tyyppi
PoE+
Power over Ethernet plus (PoE +) -porttien määrä
48
Power over Ethernet (PoE) -virta per portti
30 W
Power over Ethernet (PoE) arvioitu kokonaismäärä
410 W
Ympäristöolosuhteet
Käyttölämpötila (T-T)
0 - 50 °C
Paino ja mitat
Tuotteen leveys
440 mm
Tuotteen syvyys
310 mm
Tuotteen korkeus
44 mm
Paino
4,75 kg
Sertifikaatit
Sertifiointi
CE
FCC
UL
Edellä mainitut tiedot/tekniset tiedot ovat suuntaa-antavia ja valmistaja voi ilman varoitusta muuttaa niitä. Pidätämme oikeuden painovirheisiin ja ohjeellisiin kuviin. Jotkin tekstit voivat olla automaattisesti luotuja tai konekäännettyjä, mikä voi johtaa harhaanjohtavaan tekstiin.
