Unidrain

18200040 Vesilukko linja 50 mm sulkukorkeus

Self-cleaning trap with a capacity of 0.4-0.6 l/s depending on the outlet unit it is installed in. Meets the requirements for capacity and self-cleaning according to EN1253 (the pan-European standard for floor drains) and is VA approved. Suitable for most outlet units, including older models. Can replace water trap 1820.0010 and 1820.0040, if they are installed at the top of the drain unit. A hook to lift the water trap up from the outlet unit and a packet of silicone lubricant are included

Vaakasuuntainen P-ansaputki yksisuuntaisella lattiakaivolla, jonka halkaisija on Ø75.

Unidrain o-ring for water trap.

For shower cubicles without fixed walls.

The drain unit has four floor flanges.

Including four heght-adjustable feet (40-190 mm).

The set consists of a panel, rail, heightener set and screws. The set must be assembled before installation.

Includes 2 x hooks to be used for lifting the panel.

The panel solution is placed directly inside the drain unit.

The rail is specially designed to provide a snug fit. Installed with HighLine frame.

The heightener set to adjust the panel is included, so that the panel can be matched to the frame height.

NB: PVD-treated surface.

Kiinnityslaite Unidrain 1004 ilman reunusta, pituus 700 mm.

Meets capacity and self-cleaning requirements according to EN 1253 (the pan-European standard for floor drains) and is VA-approved.

The water trap can be removed from the outlet unit and then dismantled for cleaning.

Runko Unidrain 1500 800X12 mm.

Exclusive frame design with upper section of solid 4-mm stainless steel.

Insert ensures a snug fit inside the drain unit.

The frame enhances the exclusive design of the floor drain.

Frame available in 10, 12, 15 and 25 mm heights (depending on the thickness of the floor tile).

NB! Frame height (H) = tile thickness + approximately 2 mm for tile mortar and membrane.

Unidrain Highline CUSTOM 900 -paneeli

Puulattia Unidrain ruostumaton teräs 1810 kaikki AR.

Complete square drain set. Package includes ClassicLine Column grating and frame 10×10 cm, steel drain unit, water trap, outlet unit Ø 75 mm horizontal with side inlets, 3 x adapters (2 pcs. for 40 mm pipes and 1 pc. for 32 mm pipe). The height of the unit can be adjusted +/- 10 mm and rotated 360° in the outlet unit. Truncate the ClassicLine frame to tile level. Minimum tile layer 4 mm. Cleaning cloth included.

Lattiakaivo Unidrain 1001, 900 mm.

Complete square drain set. Package includes HighLine Custom base 10×10 cm, steel drain unit, flow guide, water trap, outlet unit Ø 110 mm horizontal with side inlets, 3 x adapters (2 pcs. for 40 mm pipes and 1 pc. for 32 mm pipe). The height of the unit can be adjusted +/- 10 mm and rotated 360° in the outlet unit. Special adhesive is included to glue your own tile to the custom base. Hook and cleaning cloth included.

Complete square drain set. Package includes ClassicLine Column grating and frame 15×15 cm, steel drain unit, flow guide, water trap, outlet unit Ø 75 mm horizontal with side inlets, 3 x adapters (2 pcs. for 40 mm pipes and 1 pc. for 32 mm pipe). The height of the unit can be adjusted +/- 10 mm and rotated 360° in the outlet unit. Truncate the ClassicLine frame to tile level. Minimum tile layer 8 mm. Cleaning cloth included.

Soap shelf including grating and mounting set. Designed for insertion in tile joint or for mounting in an existing shower cubicle. For corner installation only – applies to both models.

Lattiakaivo Unidrain 1001, 1200 mm.

Bin bags for Reframe pedal bin. 10 rolls of 25 bin bags. Black plastic (PEHD). 2 pcs. specially designed tape for easy fitting of the bag are included. Volume 4 l.

HighLine Color on valmistettu PVD-käsitellystä ruostumattomasta teräksestä. Runko on yhdistettävä paneeliin.

Sampakin kulmamalli.

Hajueste, linja 1311.0032, 1311.0050, 1312.0050, 1312.0075 ja 1417.0050

Sisältää irrotettavan vesiansan (voidaan erottaa ja puhdistaa). 180° kääntyvä, kun tarvitaan taaksepäin suuntautuva ulostulo.

Has an automatic odour barrier instead of a water trap, so that it cannot dry out. The odour barrier can be removed for cleaning. VA-approved.

– Should not be used in multi-storey buildings
– The odour barrier may react to over-pressure and under-pressure in the drain system
– Correct ventilation of the drain system is important
– The odour barrier opens and closes with the help of a spring
– A rubber seal ensures that the odour barrier is closed when not in use

Lattiakaivo Unidrain 1001, 1000 mm.
